Applications
- This data logger is meticulously designed to offer specialized features for precise aviation parameter measurement.
The SDB300™ extremely fast and powerful computing of multiple routines and uses advanced power management for very low power consumption. A true real-time executive is used to achieve multi tasking which samples and communicates simultaneously.
| General | |
| CPU | ARM |
| CPU Speed | 200 MHz |
| RAM | 64 MB |
| Data Acquisition & Control | |
| Digital Input/Output | 30X |
| Analog to Digital | 2X |
| Interface | |
| PC/104 Bus | 1X |
| 10/100 Ethernet | 1X |
| USB Host | 2X |
| Serial/COM Port | 7X |
| RS485 Port | 1X |
| SPI Bus | 1X |
| On Board Device | |
| Battery Back Real Time | 1X |
| Watchdog Timer | 1X |
| Temperature Sensor | 1X |
| Operation Temperature | |
| Fanless Temp Range | -40°C to 85°C |
| Power Details | |
| Min Power Consumption | 0.50 Watt |
| Max Power Consumption | 3.00 Watt |
| Power Supply | 4.5 – 20VDC |
| Dimensions | 206 X 150 X 70 mm |
